Technical characteristics of reverse osmosis (RO)
1. Parts and components are imported or high-quality domestic products and the technology is state-of-the-art.
2. The integration degree is high and the quality is reliable.
3. The degree of automation is high and it is able to shut down automatically due to the automatic protection function in case of failure.
4. The desalination rate is high and can be up more than 98%.
5. Imported press pumps of high efficiency and low noise are used to reduce running noise.
6. Energy consumption is reduced, thereby reducing the running cost.
7. Reasonable structure and economical space occupation save more than 30% than conventional methods.
8.The advanced membrane protection system is used, so that the demineralized water automatically washes the contaminants on the surface of membrane during the shutdown of the unit to prevent incrustation and extend membrane life.
9.The system does not consist of vulnerable parts, so maintenance is not required and long-term continuous operation is available.
10. The water volume and quality of the unit can be designed according to the requirements and using professional software to achieve the best cost performance.
The salinity (salt) concentration in water is the amount of dissolved solids in water by weight, as expressed in mg per liter or ppm. The salinity concentration level can be categorized as follows:
Tap Water . | Low TDS up to 1,000 ppm |
Brackish Water | Contains around 1,000 to 5,000 ppm. |
Highly Brackish Water | Contains around 5,000 to 12,000 ppm. |
Ocean or Seawater | Contains around 12,000 to 45,000 ppm. |
Process flow chart:
Raw water → raw water tank → booster pump → quartz sand filter → activated carbon filter → water softener (optional) → scale inhibitor → precision filter → high pressure pump → reverse osmosis device → ultraviolet sterilizer (optional) → pure water tank (effluent conductivity ≤ 10 μS/cm).
Application:
1, ordinary electroplating industry water (zinc plating, copper plating, nickel plating, etc.), coating industry, aluminum oxidation.
2, electronic power industry water, boiler water supplement.
3, chemical raw material ingredients water, cleaning water, cleaning machine matching water.
4. Deionized water for textile printing and dyeing:
5. Purified water, direct drinking water, beverage water, etc.
